Standard series

DFS 480-1/DFS 480-2//DFS 512/DFS 576/DFS 640-1/DFS 640-1/DFS 640-2

Category:

Description

Tile DFS 480-1 DFS 480-2 DFS 480-2 DFS 512 DFS 512 DFS 576 DFS 576 DFS 576 DFS 640-1 DFS 640-1 DFS 640-1 DFS 640-1 DFS 640-2 DFS 640-2 DFS 640-2 DFS 640-2
Pixel Pitch 2.5 mm 2.5 mm 5 mm 2 mm 4 mm 3 mm 4.8 mm 6 mm 2 mm 2.5 mm 4 mm 5 mm 2 mm 2.5 mm 4 mm 5 mm
Max Brightness Calibrated 1000 nits (black) 1000 nits (black) 1000 nits (black) 600 nits (black) 800 nits (black) 800 nits (black) 800 nits (black) 800 nits (black) 600 nits (black) 1000 nits (black) 800 nits (black) 1000 nits (black) 600 nits (black) 1000 nits (black) 800 nits (black) 1000 nits (black)
Panel Dimension 480 x 320 x 70 mm 480 x 480 x 90 mm 480 x 480 x 90 mm 512 x 512 x 90 mm 512 x 512 x 90 mm 576 x 576 x 90 mm 576 x 576 x 90 mm 576 x 576 x 90 mm 640 x 480 x 90 mm 640 x 480 x 90 mm 640 x 480 x 90 mm 640 x 480 x 90 mm 640 x 640 x 90 mm 640 x 640 x 90 mm 640 x 640 x 90 mm 640 x 640 x 90 mm
Panel Resolution ( H x V ) 192 x 128 192 x 192 96 x 96 256 x 256 256 x 256 192 x 192 120 x 120 96 x 96 320 x 240 256 x 192 160 x 120 128 x 96 320 x 320 256 x 256 160 x 160 128 x 128
Frame Material Diecasting Aluminum Alloy Diecasting Aluminum Alloy Diecasting Aluminum Alloy Diecasting Aluminum Alloy Diecasting Aluminum Alloy Diecasting Aluminum Alloy Diecasting Aluminum Alloy Diecasting Aluminum Alloy Diecasting Aluminum Alloy Diecasting Aluminum Alloy Diecasting Aluminum Alloy Diecasting Aluminum Alloy Diecasting Aluminum Alloy Diecasting Aluminum Alloy Diecasting Aluminum Alloy Diecasting Aluminum Alloy
Weight Per Panel 5 kg 7.5 kg 7.5 kg 8 kg 8 kg 9 kg 9 kg 9 kg 8 kg 8 kg 8 kg 8 kg 9 kg 9 kg 9 kg 9 kg
Power Consumption Max / Average 500 W / 250 W Per ㎡ 500 W / 250 W Per ㎡ 500 W / 250 W Per ㎡ 600 W / 300 W Per ㎡ 500 W / 250 W Per ㎡ 600 W / 300 W Per ㎡ 700 W / 350 W Per ㎡ 600 W / 300 W Per ㎡ 600 W / 300 W Per ㎡ 500 W / 250 W Per ㎡ 500 W / 250 W Per ㎡ 500 W / 250 W Per ㎡ 600 W / 300 W Per ㎡ 500 W / 250 W Per ㎡ 500 W / 250 W Per ㎡ 500 W / 250 W Per ㎡
Transparency Solid Solid Solid Solid Solid Solid Solid Solid Solid Solid Solid Solid Solid Solid Solid Solid
Serviceability Front / Rear Front / Rear Front / Rear Front / Rear Front / Rear Front / Rear Rear Rear Front / Rear Front / Rear Rear Rear Front / Rear Front / Rear Rear Rear
Curving (Concave & Convex) Custom 10° ~ 15° Custom 10° ~ 15° Custom 10° ~ 15° Custom 10° ~ 15° Custom 10° ~ 15° Custom 10° ~ 15° Custom 10° ~ 15° Custom 10° ~ 15° Custom 10° ~ 15° Custom 10° ~ 15° Custom 10° ~ 15° Custom 10° ~ 15° Custom 10° ~ 15° Custom 10° ~ 15° Custom 10° ~ 15° Custom 10° ~ 15°
SMD Configuration SMD2121 Black SMD2121 Black SMD2121 Black SMD1515 Black SMD2121 Black SMD2121 Black SMD2121 Black SMD3528 White SMD2121 Black SMD2121 Black SMD2121 Black SMD2121 Black SMD2121 Black SMD2121 Black SMD2121 Black SMD2121 Black
Physical Density 160,000 Pixels / ㎡ 160,000 Pixels / ㎡ 40,000 Pixels / ㎡ 250,000 Pixels / ㎡ 62,500 Pixels / ㎡ 111,111 Pixels / ㎡ 43,264 Pixels / ㎡ 27,777 Pixels / ㎡ 250,000 Pixels / ㎡ 160,000 Pixels / ㎡ 62,500 Pixels / ㎡ 40,000 Pixels / ㎡ 250,000 Pixels / ㎡ 160,000 Pixels / ㎡ 62,500 Pixels / ㎡ 40,000 Pixels / ㎡
Viewing Angle ( H / V) 160° / 140° 160° / 140° 160° / 140° 160° / 140° 160° / 140° 160° / 140° 160° / 140° 160° / 140° 160° / 140° 160° / 140° 160° / 140° 160° / 140° 160° / 140° 160° / 140° 160° / 140° 160° / 140°
Refresh Rate 3840 Hz 3840 Hz 3840 Hz 3840 Hz 3840 Hz 3840 Hz 3840 Hz 3840 Hz 3840 Hz 3840 Hz 3840 Hz 3840 Hz 3840 Hz 3840 Hz 3840 Hz 3840 Hz
Gray Scale 14 bit 14 bit 14 bit 14 bit 14 bit 14 bit 14 bit 14 bit 14 bit 14 bit 14 bit 14 bit 14 bit 14 bit 14 bit 14 bit
Scan Ratio 1/32 1/32 1/16 1/32 1/16 1/32 1/16 1/16 1/40 1/32 1/16 1/16 1/40 1/32 1/16 1/16
Operational Temp / Humidity – 20° ~ 45°C / 10-90% RH – 20° ~ 45°C / 10-90% RH – 20° ~ 45°C / 10-90% RH – 20° ~ 45°C / 10-90% RH – 20° ~ 45°C / 10-90% RH – 20° ~ 45°C / 10-90% RH – 20° ~ 45°C / 10-90% RH – 20° ~ 45°C / 10-90% RH – 20° ~ 45°C / 10-90% RH – 20° ~ 45°C / 10-90% RH – 20° ~ 45°C / 10-90% RH – 20° ~ 45°C / 10-90% RH – 20° ~ 45°C / 10-90% RH – 20° ~ 45°C / 10-90% RH – 20° ~ 45°C / 10-90% RH – 20° ~ 45°C / 10-90% RH
Storage Temp / Humidity – 40° ~ 60°C / 10-90% RH – 40° ~ 60°C / 10-90% RH – 40° ~ 60°C / 10-90% RH – 40° ~ 60°C / 10-90% RH – 40° ~ 60°C / 10-90% RH – 40° ~ 60°C / 10-90% RH – 40° ~ 60°C / 10-90% RH – 40° ~ 60°C / 10-90% RH – 40° ~ 60°C / 10-90% RH – 40° ~ 60°C / 10-90% RH – 40° ~ 60°C / 10-90% RH – 40° ~ 60°C / 10-90% RH – 40° ~ 60°C / 10-90% RH – 40° ~ 60°C / 10-90% RH – 40° ~ 60°C / 10-90% RH – 40° ~ 60°C / 10-90% RH
IP Rating (Front / Rear) IP30 / IP30 Indoor IP30 / IP30 Indoor IP30 / IP30 Indoor IP30 / IP30 Indoor IP30 / IP30 Indoor IP30 / IP30 Indoor IP30 / IP30 Indoor IP30 / IP30 Indoor IP30 / IP30 Indoor IP30 / IP30 Indoor IP30 / IP30 Indoor IP30 / IP30 Indoor IP30 / IP30 Indoor IP30 / IP30 Indoor IP30 / IP30 Indoor IP30 / IP30 Indoor

*Note: The specifications are for reference, actual values may vary.
