For 3D Print Filament UB-102
PETG is a popular 3D printer filament. The “G” stands for “glycol-modified”. This modification makes the filament clearer, less brittle and easier to use.
Description
PETG Resin For 3D Print Filament
PETG is a popular 3D printer filament. The "G" stands for "glycol-modified".
This modification makes the filament clearer, less brittle and easier to use.
PETG is a good middle ground between ABS and PLA. More flexible and durable than
PLA and easier to print than ABS.
Ubest PETG resin UB-102 series has excellent performance. The filament made
of our PETG resin will not have stringing phenomenon during the 3D printing
process, and have high strength.
We can also provide special packaging method to reduce the water absorption
of PETG resin during transportation and reduce the cost of dehumidification and
drying.
By modifying our PETG resin, we can produce high-speed printing PETG resin or
matte effect PETG resin.
| PETG resin technical parameter table | |||
| Items | Unit | Test method | UB-102 |
| Property | |||
| Intrinsic Viscosity | dL/g | Ubbelodhe viscometer | 0.780±0.015 |
| Specific Gravity | kg/cm3 | ASTM D792 | 1.29 |
| Moisture Absorption | % | ASTM D570 | 0.12 |
| Mechanical | |||
| Tensile Strength @Yield 50mm/min(2 inch/min) |
kgf/cm2 | ASTM D638 | 508 |
| Tensile Strength @Break 50mm/min(2 inch/min) |
kgf/cm2 | ASTM D638 | 292 |
| Elongation @Yield 50mm/min (2 inch/min) |
% | ASTM D638 | 5 |
| Elongation @Break 50mm/min (2 inch/min) |
% | ASTM D638 | 165 |
| Flexural Strength 1.27mm/min (2 inch/min) |
kgf/cm2 | ASTM D790 | 680 |
| Flexural Strength 1.27mm/min (3 inch/min) |
kgf/cm2 | ASTM D790 | 21200 |
| Low temperature falling dart impact | 9 | ASTM D358 | 829 |
| Atmospheric temperature falling dart impact |
9 | ASTM D358 | 1803 |
| Izod Impact Strength Notched@23℃(73°F) |
J/m | ASTM D256 | 102 |
| Hardness | |||
| Rockwell Hardness | ℃ | R-scale | 117 |
| Thermal | |||
| Heat Distortion Temperature @0.45MPa(66 psi) |
℃ | ASTM D648 | 77 |
| Melting Index | g/10min | ASTM D 1238-04 | 1.8 |
| Melting Point | ℃ | / | ≥196±2 |
| Electric property | |||
| Surface Resistivity | Ohm | ASTM D257 | 10^16 |
| Volume Resistivity | Ohm ·cm | ASTM D257 | 10^15 |
| Dielectric Strength (short time,500V/sec) |
kV ·mm | ASTM D149 | 16 |
| Dielectric Constant 1 kHz | 一 | ASTM D150 | 2.6 |
| Dielectric Constant 1 MHz | – | ASTM D150 | 2.4 |
| Dielectric Constant 1 kHz | 一 | ASTM D150 | 0.005 |
| Dielectric Constant 1 MHz | – | ASTM D150 | 0.023 |
| 防火性能/Flammability | |||
| UL Flammability Classification UL 1.00mm |
– | UL 94 | HB |
| UL Flammability Classification UL 1.50mm |
– | UL 94 | HB |
| UL Flammability Classification UL 3.00mm |
UL94 | V-2 | |
| Optical | |||
| Haze | % | / | <1.0 |
| Transmittance | % | ASDM D541 | 90 |
| Refractive Index | ASDM D542 | 1.56 | |
