BLHeli_32 3B40A 4 IN 1 ESC
The AT32F421 main control chip operates at a frequency of up to 128MHz.
Description
The AT32F421 main control chip operates at a frequency of up to 128MHz. Three in one IC drive FD6288Q drive, imported high-quality Murata capacitors, using high-end resin plug hole PCB production process, all solder pads are metallized with edges to prevent solder pads from falling off during use; 2-ounce copper thickness, 6-layer plate, greatly reducing heat generation and improving efficiency.
ESC Specifications:
Size: 44 * 44mm (20mm-20mm mounting hole)
Packaging size: 64 * 64 * 35mm
Net weight of product: 6g
Packaging weight: 41g
Electric adjustment firmware: HAKRC-40-K42_ Multi_ 32_ 8. Hex
Protocol support: PWM, Oneshot125, Oneshot42, Multispot, Dshot150, Dshot300, Dshot600
Input voltage: 2S-6S Lipo
Galvanometer ratio: 300
Continuous current: 40A
Peak current: 45A
