Alcohol tester POINT-1

Description

Point 1 (POINT-1) breath alcohol content detector is a multi-functional forensic alcohol detector developed and produced by Shenzhen Gotai Special Equipment Co., Ltd. based on the Android platform specifically for the police market. It can be fast and convenient. , accurately measure the alcohol concentration of human breath, quickly obtain evidence on site, and send the test data to the server through the 4G wireless network.

The measurement range is 0-2.5mg/L BrAC. The measurement accuracy and related requirements comply with BS EN 15964 2011 Standard or the national standard GB21254-2017 "Exhaled Gas Alcohol

Content Detector".

Processor: High-performance eight-core processor, smooth to use.

It adopts deep security customization of Android system, contains many latest processing technologies, and has comprehensive functions.

Sensor type: Imported 16 mm electrochemical fuel cell alcohol sensor is used. This sensor only reacts with alcohol and has the characteristics of long life and stable performance.

Three testing modes: quick troubleshooting, active testing and passive testing. In order to save the driver and the police testing time, first use the quick check mode to measure whether the driver is drinking. If there is alcohol, it will automatically enter the active test mode to measure the accurate alcohol concentration, or when the driver does not cooperate, a passive test can be used Mode determines whether the driver contains alcohol.

Display: 5-inch 720×1280 multi-touch capacitive screen, clear and intuitive.

Wireless network: supports a variety of wireless transmission modes, and can be selected based on 4G network (supports TD-LTE, FDD-LTE) or wireless LAN (WIFI).

Time correction function: This machine automatically updates the time within the effective range of the wireless network.

Fingerprint function: instrument management and fingerprint collection and comparison.

Positioning: Supports GPS high-precision positioning.

Dual cameras: 13-megapixel front camera and 8-megapixel rear camera. The alcohol detection process is automatically recorded, and the front camera takes photos and can be printed.

Night vision function: equipped with high-power infrared light, intelligently turn on and off the night vision camera function.

Host battery: uses type C charging interface, and the battery uses a built-in 5000 mAh rechargeable lithium battery.

Number of continuous measurements: ≥1000 times (under standard working conditions).

Storage: A single host can store ≥10 million pieces of detection information (excluding videos and photos).

Alcohol tester POINT-1

Q1: What type of sensor is it?

A: 16mm fuel cell type electrochemical sensor.

Q2: Can the alcohol test standards be customized?

A: Standards can be customized according to the laws and regulations of different countries.

Q3: How to connect to the Internet?

A: Full Netcom, 4G. Wireless function.

Q4: What is the measurement range?

A: 0-550mg/100ml(BAC).

Q5: What are the pixels of Point-1?

A: The front camera is 5 million pixels and the rear camera is 13 million pixels.

Q6: How much data can be stored?

A: It can store more than 100,000 pieces of test data.

Q7: Is there a fingerprint comparison and entry function?

A: Yes.

Q8: How to implement the positioning function?

A: Through dual positioning of GPS and Beidou.

Q9: What is the interface type?

A: The universal interface is Type-C interface.

Q10: What is the battery capacity?

A: It can reach 6300AH lithium battery.

Q11: What is the weight of Point-1?

A: About 500g, including battery.

Q12: How does the screen display?

A: 5.0-inch high-definition touch screen.

Q13: What is the size of Point-1?

A:The size is 196×83×36mm.

Q14: How to print?

A: All-in-one thermal printer.

Q15: How to prevent the blowpipe from sucking back?
