4x400G DCI MUXPONDER Platform, 16*100G 1.6T Transmission 1U Rack
4x400G DCI BOX, 16*100G 1.6T Transmission 1U Rack.4x100G QSFP28 To 400G CFP2，Maximum of 4x400G, 1.6Tbps in 1U Rack, and support 48*400G DWDM@100GHz or 64*400G DWDM@75GHz on dual fiber transmission.
Description
https://www.wdmlight.com/4x400G-DCI-MUXPONDER-Platform-16-100G-1-6T-Transmission-1U-Rack.html
Max support 16x100G for client side, 8x200G or 4x400G for line side in transmission. Total max is 1.6Tbps(3.2Tbps on bidirectional) in 1U device.
Achieve higher transfer capacity through device stacking. Maximum up to 19.2Tbps (200G*96ch@50GHz) or 25.6Tbps (400G*64 75GHz or 400G*48 100GHz)
1U chassis modular design, single board adopts hot-swappable design, supports smooth upgrade, and can flexibly expand or delete services according to needs.
Dual power supply, compatible with AC or DC power supply DC-48V.
Complete network management protocol: supports WEB, SNMP, CLI, TLI and other network management interfaces.
Support dual network management cards, 1+1 network function.
4X400G DCI BOX 1U
4x100G QSFP28 To 400G CFP2，Maximum of 4x400G, 1.6Tbps in 1U Rack, and support 48*400G DWDM@100GHz or 64*400G DWDM@75GHz on dual fiber transmission.
One service card of 400G DCI Box support 4x100G(QSFP28) for clients side, and 1x400G(CFP2) for line side. With 4 slots in 1U rack mount ,the DCI-Box max support 4x 400G transponder board，total capacity 1.6Tbps . The Device is mainly used in data center DCI interconnection and metro access and aggregation. And provide users with optical transmission solutions with different capacities, different transmission distances, and intelligent service applications.
Application
Product parameters
|
Parameter |
Describe |
|
|
Maximum capacity of a device |
8X 200G/ 4X400G 1.6Tbps |
|
|
Line side modulation mode |
DP-QPSK@100G DP-16QAM@200G; DP-8QAM@200G; DP-QPSK@200G DP-16QAM@400G |
|
|
Line side protocol |
SD-FEC/OpenROADM/OpenZR+ |
|
|
Service access type |
100GE、100GE KR4、OTU4、FlexE、OTUCn |
|
|
Standard network management function |
Support alarm real-time and historical query; support real-time monitoring of performance, real-time monitoring of coherent optical performance parameters and OSNR, adjustable VOA optical power, 100G_200G_400G multi-service access and free switching, automatic laser shutdown function (ALS), arbitrary channel spacing. Adjustable technology, up to 96 waves (@100G, @200G 50GHz) or 64 waves (@400G 75GHz), etc. |
|
|
Enhanced optional features |
Support 1000+ alarm real-time and historical query; support 1000+ performance real-time monitoring and 15-minute and 24-hour performance statistics function, Ethernet RMON statistics function, support LLDP monitoring function, support DM delay test function, support PRBS bit error test function |
|
|
Physical Network Topology |
chain, star, ring |
|
|
Network management method |
SNMP、CLI、WEB、SDN、NMS |
|
|
Environmental requirements |
Operating temperature |
-5℃~45℃ |
|
Storage temperature |
-40℃~85℃ |
|
|
Relative humidity |
5%~95% non-condensing |
|
|
Size |
446(W)x46(H)x538(D) (mm) |
|
|
Power requirements (nominal) |
220V/AC, 50Hz; -48V/DC and 280VHVDC power supply (optional) |
|
|
Power consumption |
<800W |
|
