SFP1G-SX-85
Maximum transmission distance: 550m
Transmission rate: 1.25Gbps
Package type: SFP
Wavelength: 850nm
Fiber type: SMF
Optical interface: LC
Transmitted optical power: -9.5～-3dBm
Receiver sensitivity: < -17dBm
Operating temperature: 0~70°C (32~158°F)
Description
Product Feature
● Up to 1.25 Gb/s data links
● Hot-pluggable SFP footprint
● Built-in digital diagnostic functions
● 850nm VCSEL laser transmitter
● Duplex LC connector
● Up to 550m on 50/125um MMF
● Metal enclosure, for lower EMI
● Single 3.3V power supply
● <500mW power dissipation
● Operating temperature:
Commercial: 0°C to + 70°C
Industrial: -40°C to + 85°C
RoHS Compliant and Lead-Free
Application
● 1.25 Gb/s 1000Base-LX Ethernet
● 1.063 Gb/s Fibre Channel
General Specification
| Parameter | Symbol | Min | Typ | Max | Unit | Ref. |
| Data Rate | BR | 1.06 / 1.25 | Gb/sec | |||
| Bit Error Rate | BER | 1012 | – | 1 | ||
| Fiber Length on 50/125um MMF | L | 550 | m | |||
| Fiber Length on 62.5/125um MMF | L | 200 | m |
Note1: At 1.25Gb/s with PRBS 2-23
Ordering information
| Product part NO. | Package | Data Rate | Media | Wavelength | Distance | Temperature Range |
| PGCLM85-L550-C | SFP | 1.25Gbps | MMF | 850nm | 550m | 0 ~ 70℃ Commercial |
| PGCLM85-L550-I | SFP | 1.25Gbps | MMF | 850nm | 550m | -40~85℃ Industrial |
